CHALLENGER 0

$3.00

Combining our best know-how and top-of-the-line LEDs, the new, extremely competitive Challenger series is here to challenge the market with unmatched quality at an unbeatable price. It is perfect solution to illuminate from shallow to middle-depth letters and single-sided lightboxes. Because of their sleek design, these modules can easily illuminate smaller letters ranging in depth from 30 to 160 mm. Challenger modules have a lifetime of L80 70 000 h and a 5-year warranty. Forge a new path for your signage needs with Challengers, where unparalleled quality meets affordability head-on.

Applications
  • Channel letters signs and light boxes
  • Recommended depth 30 – 160 mm
Feature and Benefits
  • Compact design
  • Efficiency up to 140 lm/W
  • IP67 protection class
  • 5-year warranty

General Data

CHARACTERISTIC
VALUE
Supply voltage 12 VDC | 24 VDC
Power 0.2 W | 0.35 W | 0.5 W
Recommended depth From 30 to 160 mm
CC distance 80 mm | 130mm
Binning 3 SDCM
Operating temperature -20°C ~ +50°C
Storage temperature -30°C ~ +60°C
Storage conditions Relative humidity <60%
IP class IP 67
Certification CE, UKCA, RoHS  compliant
Lifetime L80 70,000h
Warranty 5 years (24/7)*
